Pabovi



Código	Bitola	Parede (mm)	Ø Interno	Rolo (m)	Pressão de Trabalho
Código	Calibre	Pared (mm)	Ø Interno	Rollo (m)	Presión de Trabajo
Code	Gauge	Wall (mm)	Ø Internal	Roll (m)	Working Pressure
1109	1/2"	1.5	15,5mm	50/100	5,0 bar / 71 psi
1110	1/2"	2	15,5mm	50/100	6,0 bar / 85 psi
1111	1/2"	2.5	15,5mm	100	6,5 bar / 85 psi
1114	3/4"	1.8	20,5mm	50/100	4,0 bar / 57 psi
1115	3/4"	2.2	20,5mm	100	4,5 bar / 64 psi
1116	3/4"	2.5	20,5 mm	50/100	6,0 bar / 85 psi
1119	1"	2	25,5mm	50/100	3,5 bar / 50 psi
1120	1"	2.5	25,5mm	100	4,0 bar / 57 psi
1121	1"	3	25,5mm	100	6,5 bar / 92 psi
1138	1 1/2"	3.5	39,5mm	50/100	5,0 bar / 71 psi
1157	2"	4	50mm	50/100	4,0 bar / 57 psi
1257	3"	5	74mm	50	3,5 bar / 49 psi
